General Information
| Order Number | 2200002117 |
|---|---|
| Type | Partner Light |
| Product Type | Bar Light |
Lighting
| Input voltage | 24 VDC (+/- 5 %) |
|---|---|
| Power consumption | 96 W / 3960 mA (current controlled) |
| LED Color | Ultraviolet (UV) |
| Peak Wavelength (typical) | 395 nm |
| Light Emission | Direct |
| Light-Emitting surface | 40 mm x 1154 mm |
| Dimensions | 54,2 mm x 1189 mm x 50 mm |
| Weight | 2950 g |
| Operating Temperature | -10 °C - 40 °C |
| Relative Humidity (operating, storage) | 0 - 80 % (non-condensing) |
| Protection Class | IP65 |
| Connector Lighting | M12 socket, male, 5 pin |
Controller
| Drive method | Multi-Drive™: (Continuous or OverDrive™ strobe mode) |
|---|---|
| Pulse width | 10 µs - ∞ ms |
Conformity
- CE (incl. RoHS)
- RoHS
