ace 2 V
More Speed. Same Size. CoaXPress 2.0 on ace 2.
Interface CoaXPress 2.0
Largeur de bande élevée de 12,5 Gbps sur de longues distances et en temps réelPetit design
Peu encombrant, grâce au boîtier compact de 29 mm x 29 mmPortefeuille étendu de CoaXPress 2.0
Matériel et logiciel coordonnés pour le système de vision complet à partir d'une source uniqueMeilleur rapport qualité/prix
Excellent prix pour un système de vision complet avec les performances de CoaXPress 2.0
High performance from the sensor to the interface
Thanks to Sony's Pregius S sensors and an extensive firmware feature set, ace 2 V cameras produce images of outstanding quality. With the powerful CoaXPress 2.0 interface, the ace 2 V is perfectly suited for upgrading a Camera Link system.
Sony's Pregius S sensors
Wide resolution range from 5 MP to 24 MP
High resolution with a small sensor size thanks to small 2.74 µm pixels - ideal for a compact camera design
Images without motion artifacts, even with moving objects, thanks to global shutter combined with backside illumination
High image quality in low-light applications thanks to the excellent light sensitivity of the sensors (high quantum efficiency, QE)
Various sensor formats (including 16:9, 4:3, and 1:1) for a wide range of applications in different markets
CoaXPress 2.0 interface
Bandwidth of 12.5 Gbps for fast transmission of image data from the camera to the host system
Single-cable solution (Power over CoaXPress) for easy vision system setup
Cable lengths of up to 30 m for long distances between the vision system and host
Supports multi-camera systems that require precise synchronization and real-time capability
More products for your complete CXP-12 system
Our coordinated hardware and software components offer easy plug-and-play integration, allowing you to save development effort and receive a holistic solution that enables smooth operation at low system costs.
