General Information
| Order Number | 106697 |
|---|---|
| Product Family | dart Classic |
| Camera Category | Area Scan Camera |
Sensor
| Sensor Vendor | onsemi |
|---|---|
| Sensor | MT9P031 |
| Shutter | Rolling Shutter |
| Sensor Format | 1/2.5" |
| Sensor Diagonal | 7.13 mm |
| Sensor Type | CMOS |
| Sensor Size | 5.7 mm × 4.28 mm |
| Resolution (H x V) | 2592 px × 1944 px |
| Resolution (MP) | 5 MP |
| Pixel Size (H x V) | 2.2 μm × 2.2 μm |
| Frame rate | 14 fps |
| Mono/Color | Color |
| Spectrum | Visible |
Camera Data
| Interface | USB 3.0 |
|---|---|
| Image Data Interface | USB 3.0, nominal max. 5 Gbit/s (SuperSpeed) |
| Pixel Bit Depth |
|
| Synchronization |
|
| Exposure Control |
|
| Digital Input | 1 |
| Digital Output | 2 |
| General Purpose I/O | 2 |
| Power Supply | Via USB 3.0 interface |
| Power Requirements (typical) | 1.3 W |
Housing
| Housing Type | Board Level |
|---|---|
| Housing Size (L x W x H) | 19.9 mm x 29.3 mm x 29 mm |
| Weight | 15 g |
| Lens Mount | S-mount |
| Operating Temperature | 0 °C - 50 °C |
Technical Drawing
Manufacturer
| Basler |
|---|
Conformity
- CE (incl. RoHS)
- EAC
- FCC
- GenICam
- KC
- RoHS
- UKCA
- UL
- USB3 Vision
Features & Documentation
For more information about the features, visit the Documentation
